Deye 50 kW Hybrid inverter

Description

🔹 Detailed Description

The DEYE 50 kW 3-Phase High Voltage Hybrid Inverter (SUN-50K-SG01HP3-EU-B) is designed for large-scale hybrid and off-grid solar installations requiring maximum reliability and power.

With up to 65 kW PV input, four independent MPPT trackers, and battery voltage range of 160 – 800 V DC, it ensures optimized energy capture, minimal conversion loss, and stable operation even under demanding loads.

Engineered for Kenyan commercial and industrial environments, this inverter provides fast switchover (<10 ms), KPLC-compliant zero-export functionality, and remote monitoring via DEYE Cloud, making it one of the most advanced hybrid systems available today.

⚙️ Technical Specifications

• Rated Output Power: 50 kW (3 Phase)

• Max PV Input Power: 65 kW

• Max PV Input Voltage: 1,000 V DC

• MPPT Voltage Range: 180 – 850 V DC

• MPPT Trackers: 4 × MPPT (2 strings per tracker)

• Max PV Input Current: 26 A × 4

• Battery Type: High-Voltage Lithium-ion

• Battery Voltage Range: 160 – 800 V DC

• Max Charge/Discharge Current: 50 A

• Rated AC Output Voltage: 400 V ± 20 % (3 Phase)

• Rated Frequency: 50 / 60 Hz

• Switching Time (On/Off-Grid): < 10 ms

• Max Efficiency: 97.6 %

• European Efficiency: 97.0 %

• AC Power Factor: 0.8 lagging – 0.8 leading

• Communication Ports: RS485, CAN, Wi-Fi / GPRS (optional)

• Protection Rating: IP65 (Outdoor rated)

• Cooling: Intelligent forced-air cooling

• Operating Temperature: −25 °C to +60 °C

• Weight: ≈ 78 kg

• Dimensions: 850 × 620 × 300 mm

🌞 Key Features & Benefits

• ✅ Industrial-grade 50 kW output – ideal for large commercial facilities.

• ✅ Four MPPT trackers – maximize solar harvest under variable conditions.

• ✅ High-voltage battery design (160 – 800 V) for efficiency and stability.

• ✅ Zero-export mode – KPLC-compliant for Kenyan grid systems.

• ✅ Smart energy management via DEYE Cloud App and Web Portal.

• ✅ Time-of-use settings for intelligent charging and load control.

• ✅ Seamless transition (<10 ms) between grid and backup power.

• ✅ Compatible with major battery brands: DEYE, Hinen, Dyness, Pylontech, etc.

• ✅ Rugged IP65 housing for indoor or outdoor installation.

📍 Why Buy from Globus Solar

At Globus Solar, we design, supply, and install authentic DEYE hybrid inverters for industrial and commercial solar projects across Thika, Nairobi, and Kenya.
Our engineers ensure professional setup, integration with existing systems, and long-term after-sales support for guaranteed reliability.
